617-7200MHz 7dBi 全向車用天線
617-7200MHz 7dBi 全向車用天線
- TQC-0672UB-A
- 無線區域網路/無線網路
- 手機天線
- 617-7200
- 7
- 版本
用於2G/3G/4G/5G/WLAN系統
| TQC-0672UB-A | |||
| Application | |||
| Used in 2G/3G/4G/5G/WLAN system | |||
| Electrical specifications | |||
| Frequency range (MHz) | 617～960 | 1695～2700 | 3300-7200 |
| Polarization | Vertical | ||
| Maximum Gain (dBi) | 3 | 5 | 7 |
| Horizontal beam width (°) | 360 | ||
| Vertical beam width (°) | 75 | 50 | 30 |
| Impedance (Ω)) | 50 | ||
| VSWR | ≤3.0 | ≤2.5 | |
| Maximum power (W) | 50 | ||
| Mechanical specifications | |||
| Connector | N Female | ||
| Connector position | Bottom | ||
| Antenna size (mm) | Φ48.5*85 | ||
| Weight (kg) | ≤0.25 | ||
| Radome material | ABS | ||
| Radome color | Black | ||
| Waterproof | IP65 | ||
| Operating temperature (℃) | - 40～60 | ||
| Application | Outdoor | ||
